Reconfiguring TLS of Druid

This guide will give an overview on how KubeDB Ops-manager operator reconfigures TLS configuration i.e. add TLS, remove TLS, update issuer/cluster issuer or Certificates and rotate the certificates of Druid.

Before You Begin

• You should be familiar with the following KubeDB concepts:
  • Druid
  • DruidOpsRequest

How Reconfiguring Druid TLS Configuration Process Works

The following diagram shows how KubeDB Ops-manager operator reconfigures TLS of a Druid. Open the image in a new tab to see the enlarged version.

  

The Reconfiguring Druid TLS process consists of the following steps:

1. At first, a user creates a Druid Custom Resource Object (CRO).

2. KubeDB Provisioner operator watches the Druid CRO.

3. When the operator finds a Druid CR, it creates required number of PetSets and related necessary stuff like secrets, services, etc.

4. Then, in order to reconfigure the TLS configuration of the Druid database the user creates a DruidOpsRequest CR with desired information.

5. KubeDB Ops-manager operator watches the DruidOpsRequest CR.

6. When it finds a DruidOpsRequest CR, it pauses the Druid object which is referred from the DruidOpsRequest. So, the KubeDB Provisioner operator doesn’t perform any operations on the Druid object during the reconfiguring TLS process.

7. Then the KubeDB Ops-manager operator will add, remove, update or rotate TLS configuration based on the Ops Request yaml.

8. Then the KubeDB Ops-manager operator will restart all the Pods of the database so that they restart with the new TLS configuration defined in the DruidOpsRequest CR.

9. After the successful reconfiguring of the Druid TLS, the KubeDB Ops-manager operator resumes the Druid object so that the KubeDB Provisioner operator resumes its usual operations.

In the next docs, we are going to show a step by step guide on reconfiguring TLS configuration of a Druid database using DruidOpsRequest CRD.
