Reconfiguring Ignite

This guide will give an overview on how KubeDB Ops-manager operator reconfigures Ignite cluster.

Before You Begin

• You should be familiar with the following KubeDB concepts:
  • Ignite
  • IgniteOpsRequest

How does Reconfiguring Ignite Process Works

The following diagram shows how KubeDB Ops-manager operator reconfigures Ignite database components. Open the image in a new tab to see the enlarged version.

The Reconfiguring Ignite process consists of the following steps:

1. At first, a user creates a Ignite Custom Resource (CR).

2. KubeDB Provisioner operator watches the Ignite CR.

3. When the operator finds a Ignite CR, it creates required number of PetSets and related necessary stuff like secrets, services, etc.

4. Then, in order to reconfigure the Ignite database the user creates a IgniteOpsRequest CR with desired information.

5. KubeDB Ops-manager operator watches the IgniteOpsRequest CR.

6. When it finds a IgniteOpsRequest CR, it halts the Ignite object which is referred from the IgniteOpsRequest. So, the KubeDB Provisioner operator doesn’t perform any operations on the Ignite object during the reconfiguring process.

7. Then the KubeDB Ops-manager operator will replace the existing configuration with the new configuration provided or merge the new configuration with the existing configuration according to the MogoDBOpsRequest CR.

8. Then the KubeDB Ops-manager operator will restart the related PetSet Pods so that they restart with the new configuration defined in the IgniteOpsRequest CR.

9. After the successful reconfiguring of the Ignite components, the KubeDB Ops-manager operator resumes the Ignite object so that the KubeDB Provisioner operator resumes its usual operations.

In the next docs, we are going to show a step by step guide on reconfiguring Ignite database components using IgniteOpsRequest CRD.
