Reconfiguring PgBouncer

This guide will give an overview on how KubeDB Ops-manager operator reconfigures PgBouncer.

Before You Begin

• You should be familiar with the following KubeDB concepts:
  • PgBouncer
  • PgBouncerOpsRequest

How Reconfiguring PgBouncer Process Works

The following diagram shows how KubeDB Ops-manager operator reconfigures PgBouncer. Open the image in a new tab to see the enlarged version.

  

The Reconfiguring PgBouncer process consists of the following steps:

1. At first, a user creates a PgBouncer Custom Resource (CR).

2. KubeDB Provisioner operator watches the PgBouncer CR.

3. When the operator finds a PgBouncer CR, it creates PetSet and related necessary stuff like secrets, services, etc.

4. Then, in order to reconfigure of the PgBouncer, the user creates a PgBouncerOpsRequest CR with desired information.

5. KubeDB Ops-manager operator watches the PgBouncerOpsRequest CR.

6. When it finds a PgBouncerOpsRequest CR, it pauses the PgBouncer object which is referred from the PgBouncerOpsRequest. So, the KubeDB Provisioner operator doesn’t perform any operations on the PgBouncer object during the reconfiguring process.

7. Then the KubeDB Ops-manager operator will replace the existing configuration with the new configuration provided or merge the new configuration with the existing configuration according to the PgBouncerOpsRequest CR.

8. Then the KubeDB Ops-manager operator will perform reload operation in each Pod so that the desired configuration will replace the old configuration.

9. After the successful reconfiguring of the PgBouncer, the KubeDB Ops-manager operator resumes the PgBouncer object so that the KubeDB Provisioner operator resumes its usual operations.

In the next docs, we are going to show a step-by-step guide on reconfiguring PgBouncer database components using PgBouncerOpsRequest CRD.
