Hazelcast QuickStart

This tutorial will show you how to use KubeDB to run a Hazelcast database.

lifecycle

Before You Begin

At first, you need to have a Kubernetes cluster, and the kubectl command-line tool must be configured to communicate with your cluster. If you do not already have a cluster, you can create one by using kind.

Now, install the KubeDB operator in your cluster following the steps here. and make sure install with helm command including --set global.featureGates.Hazelcast=true --set global.featureGates.ZooKeeper=true to ensure Hazelcast and ZooKeeper crd.

To keep things isolated, this tutorial uses a separate namespace called demo throughout this tutorial.

$ kubectl create namespace demo
namespace/demo created

$ kubectl get namespace
NAME                 STATUS   AGE
demo                 Active   9s

Note: YAML files used in this tutorial are stored in docs/guides/hazelcast/quickstart/overview/yamls folder in GitHub repository kubedb/docs.

We have designed this tutorial to demonstrate a production setup of KubeDB managed Hazelcast. If you just want to try out KubeDB, you can bypass some safety features following the tips here.

Find Available StorageClass

We will have to provide StorageClass in Hazelcast CRD specification. Check available StorageClass in your cluster using the following command,

$ kubectl get storageclass
NAME                 PROVISIONER             RECLAIMPOLICY   VOLUMEBINDINGMODE      ALLOWVOLUMEEXPANSION   AGE
standard (default)   rancher.io/local-path   Delete          WaitForFirstConsumer   false                  14h

Here, we have standard StorageClass in our cluster from Local Path Provisioner.

Find Available HazelcastVersion

When you install the KubeDB operator, it registers a CRD named HazelcastVersions. The installation process comes with a set of tested HazelcastVersion objects. Let’s check available HazelcastVersions by,

$ kubectl get hzversion
NAME    VERSION   DB_IMAGE                               DEPRECATED   AGE
5.5.2   5.5.2     hazelcast/hazelcast-enterprise:5.5.2                148m

Notice the DEPRECATED column. Here, true means that this HazelcastVersion is deprecated for the current KubeDB version. KubeDB will not work for deprecated HazelcastVersion.

In this tutorial, we will use 5.5.2 HazelcastVersion CR to create a Hazelcast cluster.

Note: An image with a higher modification tag will have more features and fixes than an image with a lower modification tag. Hence, it is recommended to use HazelcastVersion CRD with the highest modification tag to take advantage of the latest features. For example, use 5.5.2.

Create a Hazelcast Cluster

The KubeDB operator implements a Hazelcast CRD to define the specification of a Hazelcast database.

Before deploying hazelcast we need to create license secret since we are running enterprise version of hazelcast.

kubectl create secret generic hz-license-key -n demo --from-literal=licenseKey='your hazelcast license key'
secret/hz-license-key created

Now we can deploy hazelcast in our cluster.

The Hazelcast instance used for this tutorial:

apiVersion: kubedb.com/v1alpha2
kind: Hazelcast
metadata:
  name: hazelcast-sample
  namespace: demo
spec:
  deletionPolicy: WipeOut
  licenseSecret:
    name: hz-license-key
  replicas: 3
  version: 5.5.2
  storage:
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 2Gi
    storageClassName: standard

Here,

spec.version - is the name of the HazelcastVersion CR. Here, a Hazelcast of version 5.5.2 will be created.
spec.replicas - specifies the number of Hazelcast nodes.
spec.licenseSecret - specifies the license created for hazelcast enterprise version.
spec.storageType - specifies the type of storage that will be used for Hazelcast database. It can be Durable or Ephemeral. The default value of this field is Durable. If Ephemeral is used then KubeDB will create the Hazelcast database using EmptyDir volume. In this case, you don’t have to specify spec.storage field. This is useful for testing purposes.
spec.storage specifies the StorageClass of PVC dynamically allocated to store data for this database. This storage spec will be passed to the StatefulSet created by the KubeDB operator to run database pods. You can specify any StorageClass available in your cluster with appropriate resource requests. If you don’t specify spec.storageType: Ephemeral, then this field is required.
spec.deletionPolicy specifies what KubeDB should do when a user try to delete Hazelcast CR. Deletion policy Delete will delete the database pods, secret and PVC when the Hazelcast CR is deleted. Checkout the link for details.

Note: spec.storage section is used to create PVC for database pod. It will create PVC with storage size specified in the storage.resources.requests field. Don’t specify limits here. PVC does not get resized automatically.

Let’s create the Hazelcast CR that is shown above:

$ kubectl apply -f https://github.com/kubedb/docs/raw/v2025.8.31/docs/guides/hazelcast/quickstart/overview/yamls/hazelcast.yaml
hazelcast.kubedb.com/hazelcast-sample created

The Hazelcast’s STATUS will go from Provisioning to Ready state within few minutes. Once the STATUS is Ready, you are ready to use the database.

$ kubectl get hazelcast -n demo
NAME               TYPE                  VERSION   STATUS   AGE
hazelcast-sample   kubedb.com/v1alpha2   5.5.2     Ready    3m

Describe the Hazelcast object to observe the progress if something goes wrong or the status is not changing for a long period of time:

$ kubectl describe hz hazelcast-sample -n demo
Name:         hazelcast-sample
Namespace:    demo
Labels:       <none>
Annotations:  <none>
API Version:  kubedb.com/v1alpha2
Kind:         Hazelcast
Metadata:
  Creation Timestamp:  2025-06-11T07:35:38Z
  Finalizers:
    kubedb.com
  Generation:        2
  Resource Version:  1180125
  UID:               c86fe3d3-276a-4124-a1cf-d7f5409ee61f
Spec:
  Deletion Policy:  Halt
  Health Checker:
    Failure Threshold:  3
    Period Seconds:     20
    Timeout Seconds:    10
  License Secret:
    Name:  hz-license-key
  Pod Template:
    Controller:
    Metadata:
    Spec:
      Containers:
        Liveness Probe:
          Failure Threshold:  10
          Http Get:
            Path:                 /hazelcast/health/node-state
            Port:                 5701
            Scheme:               HTTPS
          Initial Delay Seconds:  30
          Period Seconds:         10
          Success Threshold:      1
          Timeout Seconds:        10
        Name:                     hazelcast
        Readiness Probe:
          Failure Threshold:  10
          Http Get:
            Path:                 /hazelcast/health/ready
            Port:                 5701
            Scheme:               HTTPS
          Initial Delay Seconds:  30
          Period Seconds:         10
          Success Threshold:      1
          Timeout Seconds:        10
        Resources:
          Limits:
            Memory:  1536Mi
          Requests:
            Cpu:     500m
            Memory:  1536Mi
        Security Context:
          Allow Privilege Escalation:  false
          Capabilities:
            Drop:
              ALL
          Run As Non Root:  true
          Run As User:      65534
          Seccomp Profile:
            Type:  RuntimeDefault
      Init Containers:
        Name:  hazelcast-init
        Resources:
          Limits:
            Memory:  512Mi
          Requests:
            Cpu:     200m
            Memory:  256Mi
        Security Context:
          Allow Privilege Escalation:  false
          Capabilities:
            Drop:
              ALL
          Run As Non Root:  true
          Run As User:      65534
          Seccomp Profile:
            Type:  RuntimeDefault
      Pod Placement Policy:
        Name:  default
      Security Context:
        Fs Group:                        65534
      Termination Grace Period Seconds:  600
  Replicas:                              3
  Storage:
    Access Modes:
      ReadWriteOnce
    Resources:
      Requests:
        Storage:         2Gi
    Storage Class Name:  standard
  Storage Type:          Durable
  Version:        5.5.2
Status:
  Conditions:
    Last Transition Time:  2025-06-11T07:35:38Z
    Message:               The KubeDB operator has started the provisioning of Hazelcast: demo/hazelcast-sample
    Observed Generation:   1
    Reason:                DatabaseProvisioningStartedSuccessfully
    Status:                True
    Type:                  ProvisioningStarted
    Last Transition Time:  2025-06-11T07:37:58Z
    Message:               All desired replicas are ready
    Observed Generation:   2
    Reason:                AllReplicasReady
    Status:                True
    Type:                  ReplicaReady
    Last Transition Time:  2025-06-11T07:38:22Z
    Message:               The Hazelcast: demo/hazelcast-sample is accepting connection
    Observed Generation:   2
    Reason:                DatabaseAcceptingConnectionRequest
    Status:                True
    Type:                  AcceptingConnection
    Last Transition Time:  2025-06-11T07:38:22Z
    Message:               The Hazelcast: demo/hazelcast-sample is accepting write request.
    Observed Generation:   2
    Reason:                DatabaseWriteAccessCheckSucceeded
    Status:                True
    Type:                  DatabaseWriteAccess
    Last Transition Time:  2025-06-11T07:38:22Z
    Message:               The Hazelcast: demo/hazelcast-sample is ready
    Observed Generation:   2
    Reason:                AllReplicasReady,AcceptingConnection,ReadinessCheckSucceeded,DatabaseWriteAccessCheckSucceeded
    Status:                True
    Type:                  Ready
    Last Transition Time:  2025-06-11T07:38:26Z
    Message:               The Hazelcast: demo/hazelcast-sample is successfully provisioned.
    Observed Generation:   2
    Reason:                DatabaseSuccessfullyProvisioned
    Status:                True
    Type:                  Provisioned
    Last Transition Time:  2025-06-11T07:38:42Z
    Message:               The Hazelcast: demo/hazelcast-sample is accepting read request.
    Observed Generation:   2
    Reason:                DatabaseReadAccessCheckSucceeded
    Status:                True
    Type:                  DatabaseReadAccess
  Phase:                   Ready
Events:                    <none>

KubeDB Operator Generated Resources

On deployment of a Hazelcast CR, the operator creates the following resources:

$ kubectl get all,secret,pvc -n demo -l 'app.kubernetes.io/instance=hazelcast-sample'
NAME                     READY   STATUS    RESTARTS   AGE
pod/hazelcast-sample-0   1/1     Running   0          76m
pod/hazelcast-sample-1   1/1     Running   0          75m
pod/hazelcast-sample-2   1/1     Running   0          74m

NAME                            TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)    AGE
service/hazelcast-sample        ClusterIP   10.43.228.92   <none>        5701/TCP   76m
service/hazelcast-sample-pods   ClusterIP   None           <none>        5701/TCP   76m

NAME                                READY   AGE
statefulset.apps/hazelcast-sample   3/3     76m

NAME                                                  TYPE                   VERSION   AGE
appbinding.appcatalog.appscode.com/hazelcast-sample   kubedb.com/hazelcast   5.5.2     76m

NAME                                    TYPE                       DATA   AGE
secret/hazelcast-sample-auth            kubernetes.io/basic-auth   2      88m
secret/hazelcast-sample-config          Opaque                     2      76m

NAME                                                             STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   VOLUMEATTRIBUTESCLASS   AGE
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-0   Bound    pvc-d88feaed-2680-44f5-b2ac-5f5ec8216db8   2Gi        RWO            standard       <unset>                 76m
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-1   Bound    pvc-970da06b-a76e-442f-8350-97603efbe9df   2Gi        RWO            standard       <unset>                 75m
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-2   Bound    pvc-3bd48f9c-14f9-40af-ba5d-1e0ed6538722   2Gi        RWO            standard       <unset>                 74m

StatefulSet - a StatefulSet named after the Hazelcast instance. In topology mode, the operator creates 3 PetSets with name {Hazelcast-Name}.
Services - 2 services are generated for each Hazelcast database.
- {Hazelcast-Name} - the client service which is used to connect to the database. It points to the overseer nodes.
- {Hazelcast-Name}-pods - the node discovery service which is used by the Hazelcast nodes to communicate each other. It is a headless service.
AppBinding - an AppBinding which hold to connect information for the database. It is also named after the hazelcast instance.
Secrets - 3 types of secrets are generated for each Hazelcast database.
- {Hazelcast-Name}-auth - the auth secrets which hold the username and password for the hazelcast users. The auth secret hazelcast-sample-auth holds the username and password for admin user which lets administrative access.
- {Hazelcast-Name}-config - the default configuration secret created by the operator.

Connect with Hazelcast Database

We will use port forwarding to connect with our Hazelcast database. Then we will use curl to send HTTP requests to check cluster health to verify that our Hazelcast database is working well.

Let’s port-forward the port 8983 to local machine:

$ kubectl port-forward -n demo svc/hazelcast-sample 5701
Forwarding from 127.0.0.1:5701 -> 5701
Forwarding from [::1]:5701 -> 5701
Handling connection for 5701

Now, our Hazelcast cluster is accessible at localhost:5701.

Connection information:

Address: localhost:5701

Username:

$ kubectl get secret -n demo hazelcast-sample-auth -o jsonpath='{.data.username}' | base64 -d
admin

Password:

$ kubectl get secret -n demo hazelcast-sample-auth -o jsonpath='{.data.password}' | base64 -d
v_;HzZUg3;un~fIs

Now let’s check the health of our Hazelcast database.

$ curl -XGET -k -u 'admin:v_;HzZUg3;un~fIs' "http://localhost:5701/hazelcast/health" | jq
{
  "nodeState": "ACTIVE",
  "clusterState": "ACTIVE",
  "clusterSafe": true,
  "migrationQueueSize": 0,
  "clusterSize": 3
}

Halt Hazelcast

KubeDB takes advantage of ValidationWebhook feature in Kubernetes 1.9.0 or later clusters to implement DoNotTerminate deletion policy. If admission webhook is enabled, it prevents the user from deleting the database as long as the spec.deletionPolicy is set DoNotTerminate.

To halt the database, we have to set spec.deletionPolicy: to Halt by updating it,

$ kubectl patch -n demo hazelcast hazelcast-sample -p '{"spec":{"deletionPolicy":"Halt"}}' --type="merge"
hazelcast.kubedb.com/hazelcast-sample patched

Now, if you delete the Hazelcast object, the KubeDB operator will delete every resource created for this Hazelcast CR, but leaves the auth secrets, and PVCs.

$  kubectl delete hazelcast -n demo hazelcast-sample
hazelcast.kubedb.com "hazelcast-sample" deleted

Check resources:

$ kubectl get all,secret,pvc -n demo -l 'app.kubernetes.io/instance=hazelcast-sample'
NAME                                    TYPE                       DATA   AGE
secret/hazelcast-sample-auth            kubernetes.io/basic-auth   2      109m
secret/hazelcast-sample-config          Opaque                     2      98m

NAME                                                             STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   VOLUMEATTRIBUTESCLASS   AGE
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-0   Bound    pvc-d88feaed-2680-44f5-b2ac-5f5ec8216db8   2Gi        RWO            standard       <unset>                 98m
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-1   Bound    pvc-970da06b-a76e-442f-8350-97603efbe9df   2Gi        RWO            standard       <unset>                 97m
persistentvolumeclaim/hazelcast-sample-data-hazelcast-sample-2   Bound    pvc-3bd48f9c-14f9-40af-ba5d-1e0ed6538722   2Gi        RWO            standard       <unset>                 96m

Resume Hazelcast

Say, the Hazelcast CR was deleted with spec.deletionPolicy to Halt and you want to re-create the Hazelcast cluster using the existing auth secrets and the PVCs.

You can do it by simpily re-deploying the original Hazelcast object:

$ kubectl apply -f https://github.com/kubedb/docs/raw/v2025.8.31/docs/guides/hazelcast/quickstart/overview/yamls/hazelcast.yaml
hazelcast.kubedb.com/hazelcast-sample created

Cleaning up

To cleanup the Kubernetes resources created by this tutorial, run:

$ kubectl patch -n demo hazelcast hazelcast-sample -p '{"spec":{"deletionPolicy":"WipeOut"}}' --type="merge"
hazelcast.kubedb.com/hazelcast-sample patched

$ kubectl delete -n demo hz/hazelcast-sample
hazelcast.kubedb.com "hazelcast-sample" deleted

$  kubectl delete namespace demo
namespace "demo" deleted

Tips for Testing

If you are just testing some basic functionalities, you might want to avoid additional hassles due to some safety features that are great for the production environment. You can follow these tips to avoid them.

Use storageType: Ephemeral. Databases are precious. You might not want to lose your data in your production environment if the database pod fails. So, we recommend to use spec.storageType: Durable and provide storage spec in spec.storage section. For testing purposes, you can just use spec.storageType: Ephemeral. KubeDB will use emptyDir for storage. You will not require to provide spec.storage section.
Use deletionPolicy: WipeOut. It is nice to be able to resume the database from the previous one. So, we preserve all your PVCs and auth Secrets. If you don’t want to resume the database, you can just use spec.deletionPolicy: WipeOut. It will clean up every resouce that was created with the Hazelcast CR. Checkout the link for details.

KubeDB

KubeStash New

Stash

KubeVault

Voyager

ConfigSyncer

Guard

RESOURCES

Cassandra

Druid

Elasticsearch

FerretDB

Ignite

Kafka

MariaDB

Memcached

Microsoft SQL Server

MongoDB

MySQL

OpenSearch

PerconaXtraDB

PgBouncer

Pgpool

PostgreSQL

ProxySQL

RabbitMQ

Redis

SingleStore

Solr

Valkey

ZooKeeper
